Solar Panel Kit 10W 25000mAh Indoor Outlet Charging or Outdoor Solar Charging, 5V Input,12V/9V/6V Output with USB-A as well as Type-C Output for all Wildlife Cameras, Mobiles, Laptops | BL25A
【Continuous charging through solar energy and electric】
10W monocrystalline silicon high quality solar panel with high conversion rate up to 23% helps to save electricity to a great extent, higher than most of the products sold in the market, even on cloudy days can work normally. The solar panel is shipped with a power adptor, which allows it to be recharged using an indoor power supply on days when there is no sunlight.
【Abundant jacks and accessories】
The product is built-in 12V/9V/6V voltage output interface as well as USB-A and Type-C output interface, and is equipped with 4 DC lines: 4.0*1.7-4.0*1.7mm, 4.0*1.7-5.5*2.1-, 4.0*1.7-3.5*1.35mm, USB-A-Type-C, which can be used with all trail cameras in the market, also for charging mobile phones and tablets.
【Easy to install】
Comes with a high strength strap and universal mounting bracket, plug it in and use it immediately.
【Multi-functional Type-C port】
The Type-C port can be used as an input charging port for solar panels as well as an output port to power mobile phones and tablets.
【IP66 weatherproof】
High waterproof rating IP66 makes the solar panel highly waterproof.
Working temperature -20℃ - +60℃ (-4°F~+140°F), can meet the use of most areas.
When connected to the camera, the solar panel charger and AA battery can work at the same time.
How to Charge:
-
Charging by sunshine, please let it face sunshine, and make there is no anything on it. No matter it is connected with camera or not, it can be charged freely. And during charging process, there is no red light working.
-
Charging by DC input, please use the input power adptor for charging, which is 5V/2A. The other jack of power input needs to be inserted in solar panel( IN DC 5V). No matter it is connected with camera or not, it can be charged freely. And during charging process, red light will work.
How to Let It Work:
There are 4 output cables in gift box, please use any jack inserting to solar panel (OUT 12V, OUT 9V, OUT 6V, USB-A/Type-C), the other end needs to be inserted in device jack. During working time, red lights will not work.
Please note solar panel and AA batteries can support camera at the same time.
How to Check Power Status
There is black round button beside "IN 5V", press it, red light will work, more lighting Leds, more power in solar panel.
Specifications:
Max. Power: 10W
Li battery Capacity: 25000mAh
External Input: 5V/2A
Maximum Output: DC 12V/2.0A; 9V/2.6A; 6V/4.0A
Solar Panel Size: 260(L)*270(W)*80mm(H)
Working Temperature: -20°C to 60°C/-4°F to 140°F
Waterproof: IP66
Certificate: CE ROHS
Net Weight: 1.2KG
Gross Weight: 2.0KG
Giftbox Size: 310(L)*310(W)*80mm(H)
Accessories:
Power Cable ×4
Power Adptor ×1
Tree Mount x 1
Strap ×1
Instruction manualx1
